HMX,RMX
1.5. HMX Dimensions The following diagram shows external dimensions for the HMX truck in its standard design. Extended tip forks 9.1” 10.1” 27.0”
37.4”
28.0”
Area of ride platform 88.1”
Battery Compartment 13.3” 67° 12.5° 55.4” 47.9”
47.6”
32.3” 27.2”
61.6” 3.25”
9.1” 3.6”
14.9”
6.0” 6.1”
40.5”
4.2”
All Dimensions shown for 48” long pallet Important Use only batteries that meet the following specifications: Compartment Size: Deep Wide Battery Weight
Minimum Maximum 12.8” [325 mm] 13.3” [338 mm] 32.9” [836 mm] 33.4” [848 mm] (Consult Data plate on truck)
For smaller industrial battery sizes, provide blocking to restrain the battery from moving not more than 0.5” [12.7 mm] in any horizontal direction. 20
