1.4. RMX Dimensions The following diagram shows external dimensions for the RMX truck in its standard design. Extended tip forks 9.1” 10.1” 28.0”
27.0”
34.1”
77.7” 12 Volt 83.0” 24 Volt
67° 12.5°
Battery Compartment 8.1” 12 Volt Battery Compartment 13.3” 24 Volt
55.4” 47.6” 56.4”12 Volt 61.6” 24 Volt
32.3” 24.9” 2.3” 9.8” 30.2”12 Volt 35.4” 24 Volt
3.25” 6.0”
6.1” 4.2” Battery roller height
All Dimensions shown for 48” long pallet Important Use only batteries that meet the following specifications: Compartment Size: Deep Minimum Deep Maximum Wide Minimum Wide Maximum Battery Weight
12 Volt 24 Volt 7.6” [193 mm] 12.8” [325 mm] 8.1” [206 mm] 13.3” [338 mm] 32.9” [836 mm] 32.9” [836 mm] 33.4” [848 mm] 33.4” [848 mm] (Consult Data plate on truck)
For smaller industrial battery sizes, provide blocking to restrain the battery from moving not more than 0.5” [12.7 mm] in any horizontal direction. © BT Products
