PS S4.1 Steering Handle Head Version no
C-code
4110
T-code
000
2. Direction Control Switches The direction control switches are mounted in control handle head. It is not necessary to remove head to change switches. 1. Park the truck on a level surface and make sure parking brake is applied. 2. Release pressure in hydraulic system by pressing the lowering button on steering control handle. 3. Disconnect battery from unit to prevent accidental operation. 4. Remove six retaining screws (38) from outer edge of the switch cover (39). NOTE! Do not remove center screw (2) and nut (27). 5. Lift switch cover assembly plate off assembly and lay to one side. 6. Remove two screws (4) holding forward/rearward switch bracket (29) to housing. 7. Remove switch wires from wire harness plug and remove switches and bracket (29). 8. The switches (32,34) may now be replaced by unbolting them from the bracket (29). 9. Reconnect switch wires and reinstall bracket (29) in housing. 10. Test switch operation and adjust bracket (29) before installing switch cover plate (39). 11. Move switch cover (39) plate assembly back in place and secure with six screws (38). 12. Connect battery and test operation of all control handle functions. WARNING Testing drive function is made with drive wheel blocked off the floor. Risk of serious personal injury or possibly death may occur from run way truck.
