PS S3.5 3560 Stabilizing Caster Spring Loaded Version no
T-code
001
RMX
1. Removal NOTE! CLEANLINESS! Perform procedures in a clean environment. Make sure all parts are cleaned before disassembly and kept clean during assembly. 1. Park the truck on a level surface and make sure parking brake is applied. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 p.s.i., and then only with effective chip-guarding and personal protective equipment. 2. Release pressure in hydraulic system by pressing the lowering button on steering control handle. 3. Disconnect battery from unit to prevent accidental operation. 4. Raise and block drive end of truck so casters wheels are 2 - 3 in. [50 - 75 mm] off the floor. 5. Open access door fully. 6. Remove four cap screws and nuts securing caster assembly to torsion bar. 7. Remove caster assembly from truck. 8. Before disassembly, thoroughly clean exterior of the caster assembly in a cleaning solvent to remove all contamination. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death.
