PS S3.4 Stabilizing Caster
C-code
3560
Version no
T-code
000
392,393,394,CMX,HMX
1.1. Disassembly NOTE! CLEANLINESS! Perform procedures in a clean environment. Make sure all parts are cleaned before disassembly and kept clean during assembly. 1. Before disassembly thoroughly clean exterior of the caster assembly in a cleaning solvent to remove all contamination. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 psi. and then only with effective chip-guarding and personal protective equipment. 2. Remove screw (16) and washers (15) securing axle (5) in yoke (4). Drive axle (5) from yoke (4) slide though wheel assembly. 3. Remove hub cap (10), roll pin (9), slotted nut (8), washer (7), and roller bearing (14) from yoke (4). 4. Separate base (1) and yoke (4) removing felt seal (3) and thrust bearing (2). 5. Remove spacer washers (11) and ball bearings (12) from wheel (13).
