PS S3.3 3540 Support / Swivel Wheels Version no
T-code
001
HMX
1.2. Inspection NOTE! CLEANLINESS! Perform procedures in a clean environment. Make sure all parts are cleaned before disassembly and kept clean during assembly. 1. Thoroughly clean all parts and remove all nicks and burrs with emery cloth. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 p.s.i., and then only with effective chip-guarding and personal protective equipment. New Free Length is 6.45 in. [164 mm]
2. Inspect torsion bar (6) for excessive wear or bending. No cracks are allowed in torsion bar (6) and must be replaced if found. If heavy wear or bending is also found replace torsion bar (6). 3. Inspect pivots (3) for excessive wear or cracks. If cracks are found replace both pivots (3). 4. Inspect all bolts (4) and replace if needed. 5. All bushings are to be replaced with new.
Worn Free Length is 6.25 in. [159 mm] or Less.
6. Inspect springs (10) for wear or compression. A new spring free length measures 6.45 inches replace a spring that measures 6.25 inches or lest. NOTE! Free length is the length of the spring with no spring tension or a spring at rest.
