PS S3.3 3540 Support / Swivel Wheels Version no
T-code
001
HMX
1.1. Removal NOTE! CLEANLINESS! Perform procedures in a clean environment. Make sure all parts are cleaned before disassembly and kept clean during assembly. 1. Park the truck on a level surface and make sure parking brake is applied. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 p.s.i., and then only with effective chip-guarding and personal protective equipment. 2. Release pressure in hydraulic system by pressing the lowering button on steering control handle. 3. Disconnect battery from unit to prevent accidental operation. 4. Raise and block drive end of truck so casters wheels (8) are 2 - 3 in. [50 - 75 mm] off the floor. 5. Open access door fully. 6. Release pressure on springs (10) before removing caster assembles (8) from torsion bar (6).
WARNING Risk of injury. Spring pressure is under spring base when unbolted spring base may fly free and injury or kill. Release spring tension before removing spring base mounting bolts. 7. Remove four cap screws (7) and nuts (9) securing caster assembly (8) to torsion bar (6). 116
