PS S3.1 Drive Wheel
3500
Version no
T-code
001
4.2. Installation 1. Press drive tire (2) onto wheel hub (2). This is usually done while pressing off old tire. Press hub to center of tire.
2
1 3
2. Install drive tire and hub on axle. The drive tire retaining nut should be torqued to 250 ft-lb [339 N•m]. Failure to use a new nut could result in damage to the wheel and/or transmission.
Torque to 250 ft-lb [339 N•m]
NOTE! Replace axle nut with new nut each time drive axle is removed. Failure to replace with new nut could result in damage to drive wheel and/ or transmission.
112
