Removing the Right Speaker Module 1. Remove the Upper Cover. See “Removing the Upper Cover” on page 70. 2. Remove the two securing screws from the speaker module.
Step Speaker
Size M2.5*4 (NL)
Quantity
Screw Type
2
3. Disconnect the speaker cable from the mainboard.
4. Pull the cable completely through the housing, and remove the speaker module.
