Page 40

Advanced The Advanced screen allows the user to configure the various advanced BIOS options. IMPORTANT:Making incorrect settings to items on these pages may cause the system to malfunction. Unless you have experience adjusting these items, we recommend that you leave these settings at the default values. If making settings to items on these pages causes your system to malfunction or prevents the system from booting, open BIOS and choose Load Optimal Defaults in the Exit menu to boot up normally.

Information

Main

PhoenixBIOS Setup Utility Advanced Security Power Boot

XAdvanced Chipset Control XASF Configuration PS/2 Mouse IDE Controller SB Power Saving Feature: On chip SATA SATA Class ID SATA IDE Combined mode PATA Channel Config ACHI ROM POST delay

[Auto Detec] [Disabled] [Enabled] [Enabled] [IDE-ACHI C] [Disabled] [SATA as pr] [Disabled]

USB Host Controller: Legacy USB Support: Option ROM Placement

[Enabled] [Enabled] [Disabled]

Large Disk Access Mode: Installed O/S: Reset Configuration Data Processor Assisted Virtualization:

[DOS] [Other] [No] [Enabled]

F1 Help ESC Exit

↑↓ Select Item ←→ Select Menu

F5/F6 Change Item Enter SelectXSubmenu

AMD Exit Item Specific Help Select options for Advanced Chipset features.

F9 Setup Default F10 Save and Exit

The table below describes the items, menus, and submenus in this screen. Settings in boldface are the default and suggested parameter settings. Parameter

28

Description

Submenu Items

Advanced Chipset Control

Enter the Advanced Chipset Control menu.

• •

Advanced NB Options Advanced SB Options

ASF Configuration

Enter the ASF Configuration menu.

• • • • •

ASF OS Device Availability Minimum Watchdog Timeout BIOS Boot Timeout OS Boot Timeout Power-on wait time

PS/2 Mouse

Enable or Disable PS/2 Mouse port IRQ12.

Option: Auto Detect, Enabled, or Disabled

IDE Controller

Configure the Integrated Local Bus IDE Controller.

Option: Disabled, Both, or Primary

SB Power Saving Feature

Enable SB Power Saving Feature.

Option: Enabled or Disabled

Chapter 2
