LAN Interface Item
Specification
LAN Chipset
RealTek 8111C for GIGA LAN
Supports LAN protocol
Integrated 10/100/10000BASE-T transceiver
LAN connector type
RJ-45
LAN connector location
Left side
Features
•
Automatic MDI crossover function
•
PCIe V1.1 compliant
•
10/100/10000BASE-T full -duplex/half -duplex MAC
•
Receive side scaling (RSS) for multi-core processors
•
IPv4 and IPv6 large send offload and checksum offload (LSO/TCO)
•
Wake on LAN (WOL) support meeting the ACPI requirements
•
Statistics for SNMP MIB II, Ethernet-like MIB, and Ethernet MIB (IEEE 802.3z, Clause 30)
•
Self-boot feature, utilizing smaller EEPROM size
•
Serial flash memory support
•
SMBus interface supporting Alert Standard Format (ASF) v2.0
•
Hot Plug support
•
PCI Express CLKREQ# support
•
Energy Detect/Cable sense
•
68-pin QFN package
Bluetooth Interface Item
Specification
Chipset Data throughput Protocol Interface Connector type Wireless Module 802.11b/g Item
Specification
Chipset Data throughput Protocol Interface
