Jumper and Connector Locations Top View
Item
Description
Item
Description
JEXP1
NewCard Connector
LED1
Power LED
JLVDS1
LCE Connector
LED2
Battery LED
JMDC1
Modem Connector
LED3
Wireless LED
JP10
Bluetooth Connector
LED4
Bluetooth LED
JP13
Internal TouchPad Connector
SW1
Left Button
JP15
Internal Keyboard Connector
SW2
Right Button
JP19
Speaker Left Connector
SW3
Wireless Button
JP20
Speaker Right Connector
SW4
Bluetooth Button
JP29
To PWR/B Connector
SW5
Volume Up Button
JP30
To Lid SW/B Connector
SW6
Volume Down Button
JP31
To LED/B Connector
SW7
e-Key Button
JP32
Internal MIC Connector
SW8
Arcade Button
