Electrical systems – 5000 Parameters Order number 229735-040
Date 2005-11-04
Valid from serial number 904519-
T-code 781
Table 22: Parameter #39 settings Method
Operator can change driver parameters
CAN key required to change driver parameters
Value Key switch fitted
1
2
Keypad fitted (standard 10 PIN codes)
3
4
Extended keypad (100 PIN codes)
5
6
Keypad + TLS
7
8
Smartcard
9
10
Smartcard + TLS
11
12
Extended keypad - General The truck can be programmed with a maximum of 10 operator profiles. The extended keypad then enables a maximum of 10 PIN codes to be assigned to each operator profile. This makes it possible to handle up to 100 different PIN codes. If the extended keypad is activated, handling of standard PIN codes that are normally accessible via parameter #10 is ignored.
Extended keypad - Programming A group of PIN codes can be made accessible by defining them as a block. Block no. 0 is activated in the default setting. This means that 3 different operator profiles can be accessed from the very start. Activation of other blocks will make all the PIN codes for that block accessible (see Table 24:). If all 10 blocks have been activated, then 10 PIN codes will be accessible for the operator profile. The truck firmware stores a standard PIN code set as depicted in Table 24:. These PIN codes can be adjusted to any value, however, it is advisable to avoid identical PIN codes in different operator profiles. Starting programming using the extended keypad: • Connect a suitable CAN service key to X41. • Enter code 341671 and depress
on the keypad.
• Select a programming command from Table 23:
© TIEE SARL
Service Manual
7SM08F
11- 49
