Electrical systems – 5000 Parameters T-code 781
Valid from serial number 904519-
Date 2005-11-04
Order number 229735-040
Table 21: Battery size parameter Value
Function
3
¦
4
Less discharged
5
Battery (Ah)
230 Ah (Standard)
6 7
More discharged
8
ý
WARNING! Ensure you have set the parameter correctly. The battery may otherwise be irreparably damaged.
#22 - [S10] Type This parameter is only used for other older truck models which use a mechanical [S10] switch. It is always set to 0 in this truck type.
#25 - Service interval This parameter determines the time value in hours to the next service from 50 to 2000 hours in steps of 50 hours. Whenever this value is changed the timer is reset and will start counting activity time up to the set value. On reaching the set value caution code 29 (C29) will be shown on the display. The standard value for this parameter is 0, which means the timer is turned off.
#28 - Forks lift button selection This parameter determines which buttons are used for forks lift function. • Value 0 - No buttons active. • Value 1 - A2:S19 & 20 operate forks / A2:S21 & 22 operate support arms (default). • Value 2 - A2:S21 & 22 operate forks / A2:S19 & 20 operate support arms.
#39 - Log-in method & operator parameter access This parameter determines which function will be used for log-in and whether or not the operator is allowed to adjust the operator parameter settings.
11- 48
