Electrical systems – 5000 Parameters T-code 781
Valid from serial number 904519-
Date 2005-11-04
Order number 229735-040
11.11.8 Description of service parameters # 10 - PIN code NOTE: The functionality of parameter #10 is ignored if the value of parameter #39 has been set to 5, 6, 7 or 8. PIN code input is facilitated via the extended keypad. For detailed information, see the section Extended keypad - General on page 49.
The parameter stores the truck’s active PIN-codes. The truck can store up to ten PIN-codes. Each PIN-code has a set of parameters associated with it, called driver Parameters. Entering a particular PIN-code at start-up will make the selected PIN-code’s driver parameters active. This allows up to ten operators to individually adjust the characteristics of the truck. On delivery the truck has one default PIN-code stored which is “1“.
To enter a new PIN-code: • Operate L1 repeatedly in the forward direction to select parameter #10. After one second, the display will show the PIN-code for this driver. • Repeat the step above until parameter #10 for the next driver is displayed, the display will either show PIN-code for that driver OR “0”(zero). • Repeat the step above until the PIN-code displayed is “0” (zero) • Press Horn button S18
Parameter symbol flashes. • Operate L1 to set the desired value of the new PIN-code.1 • Press Horn button S18
Parameters symbol lights (stops flashing). The new PIN-code has now been entered.
To remove an existing PIN-code: • Operate L1 repeatedly in the forward direction to select parameter #10. After one second, the display will show the PIN-code for this driver.
1.Operating L1 lightly will step the value in increments of 1. Operating L1 fully will step the value in increments of 100. Valid values are 1 to 9999. 11- 44
Service Manual
7SM08F
© TIEE SARL
