Electrical systems – 5000 Parameters T-code 781
Valid from serial number 904519-
Date 2005-11-04
Order number 229735-040
11.11.6 Description of driver parameters #1 - Maximum speed in Turtle mode Parameter #1 allows for adjustment of the maximum speed of the truck when Turtle mode is in operation. Turtle mode allows the operator to temporarily reduce the maximum speed of the truck by pressing option button 1. Pressing the button alternately toggles the function on and off. For Turtle to operate, it must first be activated by setting a non-configurable option #15. See section “ #15 - Non-configurable options” for information about how to activate Turtle mode.
#2 - Maximum speed Allows adjustment of the maximum speed of the truck.
#3 - Maximum acceleration Allows adjustment of the truck’s maximum acceleration. The lower the value of the parameter the longer it takes to accelerate the truck to the demanded speed control lever position [L1].
#4 - Neutral braking force Allows adjustment of the neutral braking force applied when speed control lever [L1] returns to the neutral position. The lower the value of the parameter the longer it takes to bring the truck to a standstill.
#5 - Automatic log-off This parameter determines the time interval, in minutes, after which automatic log-off takes place if the truck is not used. The value “0” (zero) results in log-off after 4 hours.
11- 42
