Electrical systems – 5000 Electrical component list T-code 781
Valid from serial number 904519-
Date 2005-11-04
Order number 229735-040
Table 5: Electrical component list Inf.
A2:S17
Emergency reverse
Hall sensor
Fig. 6
Fig. 2
5
S10
Tiller arm in drive position (Mechanical brake activation)
Inductive proximity switch
Fig. 4
Fig. 3
7, 10
S18:1
Horn activation - lefthand
Switch
Fig. 7
Fig. 2
7
S18:2
Horn activation - righthand
Switch
Fig. 7
Fig. 2
7
S21
Emergency switch-off
Switch
Fig. 5
Fig. 3
Y1
Mechanical brake
Electromechanical brake
Fig. 4
Fig. 3
7
H1
Audible warning signal - Horn
Horn
Fig. 4
Fig. 3
7
L1
Speed control and travel direction selector (butterfly)
Hall sensor
Fig. 2
6, 7
S113
“Turtle” function
Switch
Fig. 7
M1
Truck traction
Motor
Fig. 4
Fig. 3
Designation
Picture ref.
Component type
Diagram ref.
Function
Braking, Safety & Supervision
Traction
3
Forks lift A2:S19
Fork lift control
Hall sensor
Fig. 6
Fig. 2
7
A2:S20
Fork lower control
Hall sensor
Fig. 6
Fig. 2
K30
Pump motor activation
Contactor
Fig. 4
Fig. 3
Y34
Fork lift cylinder selection-hydraulic control
Magnetic valve
Fig. 5
Fig. 3
7
Y41
Lower -hydraulic control
Magnetic valve
Fig. 4
Fig. 3
7
M3
Hydraulic pressure
Motor
Fig. 4
Fig. 3
Support arm lift A2:S21
Support arm lift control
Hall sensor
Fig. 6
Fig. 2
5,7
A2:S22
Support arm lower control
Hall sensor
Fig. 6
Fig. 2
5,7
S31
Support arms at top supervision
Inductive proximity switch
Fig. 5
Fig. 3
7,-9
Y52
Support arm lift cylinder selectionhydraulic control
Magnetic valve
Fig. 5
Fig. 3
7
11- 6
