Drive unit/gear – 2000 Leakage from top cover Order number 229735-040
Date 2005-11-04
Valid from serial number 904519-
T-code 781
Pos Description
Note
27
Screw
Motor and gear housing
28
Nut
Tightening torque 26.6 Nm Lock with Loctite 242
29
Conical roller bearing
30
Shims
31
Seal
32
Drive shaft
8.2 Leakage from top cover 8.2.1 Dismantling • Lift up the truck, and block up to ensure that it is stable. • Unscrew the drive wheel. • Unscrew the M8 nuts (28), that hold the gear and motor, with a box wrench. Support the gear so that it does not drop. • Release the M8 bolts (12), that hold the cover (3), with a 6 mm hex socket wrench. • Change the gasket (6).
8.2.2 Assembling is carried out in the reverse order • Tighten the four M8 bolts and the four M8 nuts to a torque of 26.6 Nm Lock with Loctite 242. • Tighten the drive gear’s 5 bolts to a torque of 65 Nm.
© TIEE SARL
Service Manual
7SM08F
8- 3
