OPERATOR’S STATION 1
Heater (Optional) Operation 1- Heater Switch 2- Vent 3- Front Window Defroster Heater Switch Operate heater switch (1) to activate the heater.
M4FG-01-015
OFF .... The heater operation is stopped. LO ....... Blown out warm air volume decreases. HI ........ Blown out warm air volume increases.
Vent Manually open heater unit cover (2) to adjust heater operation. 1
fNOTE: When the front window pane becomes frozen: If the
M4EJ-01-060
front window pane becomes frozen in winter or when atmospheric temperature is low due to snow falling, close vent cover (2) and turn heater switch (1) to the HI position. Full warm air is blown out from three front window defrosters (3), allowing the frozen front window pane to be quickly defrosted.
2
M4FG-01-049
3
M4EK-01-060
1-36
