OPERATOR’S STATION Key Switch WARNING: Before starting the engine, return d the F-N-R lever to neutral (N) position, apply the parking brake, and lock the loader control lever and the auxiliary control lever (optional). Refer to the descriptions in the “OPERATING ENGINE“ chapter for the detail information.
1
WARNING: Never turn key switch (1) OFF while d traveling the machine. Failure to do so may cause
M4FG-01-015
steering wheel and brakes are out of control, possibly creating a dangerous situation. Failure in the electrical system and/or base machine may result. A : HEAT
B A
C D
(Preheat)
B : OFF
(Engine Off )
C : ON
(Engine On)
1
D : START (Engine Start)
M4EJ-01-025
eco Mode Switch
2
When eco mode switch (2) is turned ON, HST pump and motor control programs are changed in order to prevent rapid increase of the engine speed. This function helps to reduce fuel consumption. When eco mode switch (2) is turned ON, orange light (3) comes ON.
M4FG-01-015
3
ON
2
OFF M4FG-01-045
1-34
