OPERATOR’S STATION C
Loader Control Lever
B
Mono-Lever Type Is used to operate the lift arm and/or bucket. (C) Float
E N
: The lift arm free falls and can be moved as loads are applied.
D G
A
(B) Lift Arm Lower (N) Hold
: The lift arm and bucket are stopped and held in that position.
(A) Lift Arm Raise (E) Bucket Dump : The bucket is tilted forward to dump the bucket load. (D) Bucket Tilt
: The bucket is tilted back, taking the transportation position.
(G) Detent
: When the loader control lever is moved from the bucket dump position to the bucket tilt position, the loader control lever is maintained in this position.
M4FG-01-023
fNOTE: After dumping the bucket, when loader control lever (1) is pulled further from the TILT position (D), the lever is held in that position (G). Then, as soon as the bucket is tilted up to the position set by the bucket auto-leveler, loader control lever (1) is automatically returned to the HOLD position (N).
C B
D
E N A M4GB-01-074
M4EJ-01-031A
1-31
