OPERATOR’S STATION Front Window Wiper Switch (Cab Vehicle) IMPORTANT:
The washer motor may become damaged if washer fluid is continuously used for more than 20 seconds or the wiper switch is operated with no fluid in the washer tank. Take care about the switch operation time and the fluid level in the washer tank.
1
Operate front window wiper switch (1) to move the windshield wiper.
2 M4FG-01-020
OFF ....... The wiper stops moving and the wiper blade is returned to the pre-start position. LO .......... The wiper operates at slow speed. HI ........... The wiper operates at fast speed. PUSH..... As long as wiper switch (1) is depressed, the washer fluid is dispensed.
1
2 M4FG-01-044
Rear Window Wiper Switch (Cab Vehicle) IMPORTANT:
The washer motor may become damaged if washer fluid is continuously used for more than 20 seconds or the wiper switch is operated with no fluid in the washer tank. Take care about the switch operation time and the fluid level in the washer tank.
Operate rear window wiper switch (2) to move the windshield wiper. OFF ....... The wiper stops moving and the wiper blade is returned to the pre-start position. LO .......... The wiper operates at slow speed. PUSH..... As long as wiper switch (2) is depressed, the washer fluid is dispensed.
1-28
