OPERATOR’S STATION Parking Brake Switch To prevent the occurrence of accidents d WARNING: due to running away of the machine, be sure to
1
apply the parking brake when parking the machine and before leaving the machine. Do not apply the parking brake while traveling the machine except in an emergency. Apply the parking brake only after the machine has stopped. Failure to do so may cause sudden deceleration of the machine travel speed, possibly creating a dangerous situation. Premature wear and/or damage to the parking brake may result. After the parking brake has been applied in an emergency while traveling the machine, have the parking brake checked at your nearest TCM dealer. When parking brake switch (1) is turned ON, the parking brake is applied, and parking brake indicator (2) and service indicator (3) come ON. Press the OFF side of parking brake (1) to release the parking brake. Check that parking brake indicator (2) and service indicator (3) go OFF by pressing the switch twice with clicks.
fNOTE: • The parking brake is released by hydraulic pressure only when the engine is running. • To ensure safe operation, when the parking brake is applied, even though the F-N-R lever is moved to forward (F) or reverse (R) position, the machine does not travel. • To ensure safe operation, when the engine is stopped, the parking brake is applied even if parking brake switch (1) is in the OFF position. Before starting the engine, check that the F-N-R lever is in the neutral (N) position. Then, turn the parking brake switch (1) ON.
1-26
M4FG-01-020
1
ON
OFF
M4EK-01-025A
3 2
M4FG-01-011
