OPERATOR’S STATION Steering IMPORTANT:
When the steering wheel is fully turned, the front and the rear frames come in contact with the stoppers so that the steering wheel does not rotate further. If the steering wheel is forcibly turned moreover, the engine may stall or malfunction of the steering system may result.
1
2
M4FG-04-002
Horn Switch Press horn switch (2) to sound the horn.
3
Turn Signal Lever Indicates the drive change direction to persons and/or other vehicles by operating turn signal lever (3). Return turn signal lever (3) to neutral manually.
L
N
L : Left Turn R : Right Turn
R
Dimmer Switch
M4FG-01-020
The dimmer switch shifts the headlight beam high and low.
4
Travel the machine with the headlight d inCAUTION: the low beam position when other vehicles are present in the vicinity. After turning the headlight ON, when turn signal lever (3) is lowered, the headlight beam is set in the high position and high beam indicator (4) comes ON. When the turn signal lever is raised, the headlight beam is set in the low position and high beam indicator comes OFF. M4FG-01-011
1-21
