OPERATOR’S STATION Shifting Item to Be Indicated on Machine Information Display Press monitor display selector (1) to shift the display item once at a time.
M4FG-01-011
1
Hour Meter
When monitor display selector (Δ) (1) is pressed once:
Indicates the total machine operating hours up to present. In case the operating hour exceeds 99999.9 h, the meter restarts counting the hour from 0 hour. The hour meter will be locked after third round of 99999.9 h. When this display is indicated, press monitor display selector (1) once to display the odometer.
Hour Meter
Press button
press button
Odometer
Odometer Indicates the total machine traveling distance up to present.
M4FG-01-017
1-16
