OPERATOR’S STATION 1
Forward/Reverse and Shift Position Indicator F-N-R/Shift position indicator (1) displays the selected travel mode. • Forward : 2 stages • Reverse : 2 stages
M4FG-01-012
F-N-R (Forward/Reverse) Position Indicator When F-N-R lever (4) is placed in forward (F), neutral (N), or reverse (R) position, F-N-R position indicator (2) indicates the selected F-N-R lever position by lightening the corresponding indicator in square ( ). (F-N-R indicates the selected F-N-R lever position.)
2 3
Shift Position Indicator When F-N-R lever (4) is in either the forward or reverse position, shift position indicator (3) displays the shift stage selected by Hi - Lo selector switch (5).
M4FG-01-013
4
• Hi : Auto Shift 2-Speed Mode • Lo : 1-Speed Mode F N
R
5 M4FG-01-014
5
M4FG-01-056
1-13
