OPERATOR’S STATION Engine Coolant Temperature Gauge The engine coolant temperature is indicated with a needle. When the needle stays in the blue range (1) during operation, the coolant temperature is normal. If the engine coolant temperature becomes abnormally high, the stop indicator will flash. Stop machine operation and run the engine at low idle to lower the coolant temperature. After the coolant temperature lowers, stop the engine for inspection. In case the needle does not swing at all, Error in the electrical system is suspected. Contact your nearest TCM dealer for machine inspection.
1
M4GB-01-028
Fuel Gauge The remaining fuel amount is indicated by the needle. Fuel the machine before the needle indicates the red range (E).
M4GB-01-030
1-10
