OPERATOR’S STATION Stop Indicator (Red) WARNING: Prevent possible casualty and/or machine d damage. If the stop indicator flashes and the alarm buzzer sounds, immediately stop machine operation. Then, check and service the section displaying the trouble. The stop indicator flashes and the alarm buzzer sounds if one of the following cases below occurs. Immediately, stop operating the machine. Move the machine to a safe area. Park the machine and stop the engine. Contact your nearest TCM dealer for machine inspection:
M4GB-01-010
• If the engine oil pressure decreases, • If the engine coolant temperature abnormally increases, • If the brake oil level decreases,
Service Indicator (Yellow) The service indicator comes ON if one of the following cases as described below occurs. Immediately, stop the engine. Check the cause of the trouble. • If the alternator voltage decreases or becomes excessively high, • If the air cleaner is restricted, • If any abnormality is found in HST operation, • If the indicator comes ON when the parking brake is applied,
1-7
M4GB-01-011
