OPTIONAL ATTACHMENTS Installation WARNING: Be sure to complete installation work only d after checking that coupler pins (6) (both right and
d
6
6
left) have been installed. WARNING: Apply the parking brake before leaving the machine.
IMPORTANT:
Apply grease onto coupler pin (6) to prevent seizing and rust before installing the attachment.
M4EK-PLOW-066
1. After checking that coupler pins (6) have been removed. Slowly approach the machine to the bucket (attachment) hooks until the hooks are inserted into the quick coupler. IMPORTANT:
Take care not to pinch hydraulic hoses between the quick coupler and the attachment.
7
2. Slightly raise lift arm (7) to slowly allow the bucket (attachment) to tilt backward until stopper (8) on the bucket comes in contact with quick coupler stopper (8).
8
M4EK-13-004
3. Move auxiliary control lever (9) reverse (Install) to install coupler cylinder pins (6) (left and right).
fNOTE: Disconnect hydraulic hoses from the coupler cylinder
of the quick coupler, connect them to the attachment cylinder.
M4EK-13-005
Remove
9
Install
M4EK-PLOW-063
13-5
