OPERATING MACHINE Grading IMPORTANT: Be sure to perform grading work while driving the machine in reverse. If grading work is performed by driving the machine forward, severe loads are applied to the front attachment, possibly creating cracks or damage to the front attachment.
M4EK-05-009
1. After filling soil into the bucket, dump the bucket gradually to disperse soil while driving the machine in reverse. 2. Lower the bucket teeth tips onto the ground. Grade and level the ground surface while driving the machine in reverse with the bucket teeth tips dragging. 3. After filling the bucket with a load such as soil, position the bucket level with the ground surface. Finish the ground surface utilizing the bucket weight. At this time, drive the machine in reverse with the lift arm held in the FLOAT position.
M4EK-05-010
M4EK-05-011
5-8
