OPERATING MACHINE Digging and Loading Level Ground IMPORTANT:
While excavating with the bucket or fork, never apply excessive traction force to the tooth tips with the bucket or fork tiled more than 10 degrees. Failure to do so may result in cracking or damaging the work tools. M4EK-05-005
Slightly position the bucket teeth downward (0 to 10 degrees) and dig the ground while driving the machine forward as described below. Always take care not to apply loads to only to one side of the bucket. 1. Position the bucket teeth slightly downward. 2. While driving the machine forward, tilt the bucket so that the ground surface is gradually separated. 3. Adjust the digging depth by operating the lift arm.
M4EK-05-006
4. Drive the machine with the bucket tilted backward fully and held at the lowest possible position.
M4EK-05-007
M4EK-05-008
5-7
