OPERATING MACHINE Excavation Loading Accumulated Soil IMPORTANT:
Avoid operating the machine with the front wheels raised off the ground. Machine traction force is reduced and excessive loads are applied to the undercarriage.
Scoop load while driving the machine forward as described below. As load increases the wheels begin to slip, slightly raise the bucket to reduce the load.
M4EK-05-001
1. Level the bucket with the surface of the ground. Penetrate the bucket into the accumulated soil while driving the machine forward. 2. After the bucket has sufficiently penetrated the soil, raise the lift arm while driving the machine forward further and occasionally tilt the bucket back to fill the bucket. 3. If it is difficult to penetrate the soil with the bucket, move the bucket back and forth and the bucket teeth up and down.
M4EK-05-002
4. Drive the machine with the bucket tilted backward fully and held at the lowest possible position.
M4EK-05-003
M4EK-05-004
5-6
