OPERATING MACHINE Lever Locks WARNING: When locking the loader control lever and d the auxiliary control lever (3) (optional), securely
1
shift lever locks (2), (4) to the LOCK position. Unless lever locks (2), (4) are fully moved to the LOCK position, the control levers are not locked, possibly creating a hazardous situation. Before leaving the operator’s seat, be sure to stop the engine. Then, move lever locks (2), (4) to the LOCK position. After completing operation of the machine or transporting the machine, be sure to move lever locks to the LOCK position. Lever locks (2), (4) are provided to prevent the machine is unexpectedly operated even if the operator mistakenly comes in contact with loader control lever (1) or auxiliary control lever (3) (if equipped) when getting on or off the machine. When loader control lever (1) and auxiliary control lever (3) (optional) is placed to the UNLOCK position, the levers becomes operable.
LOCK
UNLOCK
2 M4FG-01-023
4
3
fNOTE: Auxiliary control lever (3) and lever lock (4) are
UNLOCK
optional.
Loader Control Lever Lock Operation
LOCK
• When leaving the operator’s seat: 1. Park the machine on solid level ground. Lower the bucket to the ground. Return all levers to neutral. Stop the engine. 2. Be sure to move lever lock (2) in the LOCK position. Be sure to place lever lock (4) in the LOCK position when auxiliary control lever (3) is not in use. • Before starting operation: Before starting operation, check that lever lock (2) is in the UNLOCK position. Be sure to place lever lock (4) in the UNLOCK position when auxiliary control lever (3) is in use.
5-2
Auxiliary Control Lever (Optional)
M4FG-01-024
