DRIVING MACHINE Steering WARNING: Avoid sudden steering changes while d driving at fast speed and driving on a slope. Do not stop the engine while driving the machine. If the engine is stopped, the steering becomes heavy. Avoid sudden steering operation with the lift arm raised to a high enough position. Failure to do so may possibly cause the machine to turn over. IMPORTANT:
When the steering wheel is fully turned, the front and the rear frames come in contact with the stoppers so that the steering wheel does not rotate further. If the steering wheel is forcibly turned moreover, the engine may stall or malfunction of the steering system may result.
Turn the steering wheel towards the direction you intend to steer the machine during drive operation.
fNOTE: The front and rear frames are coupled by a
connection pin (center pin) so that the rear wheels follow the tracks of the front wheels. Turn the steering wheel smoothly so as to follow the motion of the machine.
