DRIVING MACHINE Parking Brake Switch WARNING: To prevent the occurrence of accidents d due to running away of the machine, be sure to apply
ON OFF
the parking brake when parking the machine and before leaving the machine. Never apply the parking brake by operating parking brake switch (1) while traveling the machine except in an emergency. Premature wear and/or damage to the parking brake may result. If the parking brake was applied while traveling the machine because of an emergency, have the parking brake inspected by your nearest TCM dealer. • Press the OFF side of parking brake switch (1) to release the parking brake. Check that parking brake indicator (5) and service indicator (4) go OFF by pressing the switch twice with clicks. Press the ON side of parking brake switch (1) to apply the parking brake. Operate the parking brake after parking the machine on level ground.
1
M4FG-01-020
2
fNOTE: While running the engine, when the parking brake is applied with F-N-R lever (2) in neutral, parking brake indicator (5) and service indicator (4) come ON.
• While running the engine, when the parking brake is applied with F-N-R lever (2) in either the forward (F) or reverse (R) position, parking brake indicator (5) and service indicator (4) come ON, and the alarm buzzer sounds. The monitor display indicates (3) “N” not “F” and “R”. The monitor display will not indicate “F” and “R” until the parking brake is released. • In order to ensure safe operation, the parking brake is automatically applied when the engine is stopped even though parking brake switch (1) is OFF. In this case even after the engine is restated, the parking brake will not be released. After starting the engine, push OFF position of parking brake switch (1) to release the parking brake.
4-4
M4FG-01-014
3
4
5
M4FG-01-011
