OPERATOR’S STATION Door Lock Knob
5
CAUTION: After closing the door, always check that d the door lock is securely engaged. Depress door lock knob (5) to engage the door lock.
Door Open/Close Lever When opening the door, while lifting door lock knob (5), pull lever (6) to disengage the door lock.
6
Window Open/Close Levers
M4EK-01-046
7
When window open/close levers (7) on both sides are simultaneously pressed, the window is unlocked, allowing the windowpanes to move. When window open/close levers (7) are released, stoppers are engaged in the nearest steps so that the window is locked in that position.
M4EK-01-047
7
LOCK UNLOCK
M4EK-01-048
1-52
