Travel Unit
TE RN
AL
6) Remove the 2 springs [330] and 2 valves [327] from the rear flange [301].
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
• Do not reuse the removed O-ring [338].
IN
7) Remove the O-ring[338] from the plug [382]. Note
[12] Removal of the pilot valve within the rear flange
1) Remove the plug [382] from the rear flange [301]. 2) Remove the O-ring [338] from the plug [382]. Note
• Do not reuse the removed O-ring [338].
3) Remove the spool [363] and spring [366] from the rear flange [301].
42
ASM-17-21-002EN 15
