Travel Unit 3. Disassembly Procedure [1] Cleaning of travel motor 1) Tighten the eyebolts into the threaded installation holes on the spindle [2]. Note
TE RN IN
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
3) Clean each travel motor part with a vehicle washing brush. Note • Dirt enters the gap (floating seal installation section) between the hub [1] and spindle [2], so clean this area especially thoroughly.
E
2) Hang the wire on the eyebolts, lift the travel motor with a liftcrane, and move it to the cleaning tank.
AL
• Tighten the 2 eyebolts into the threaded spindle installation holes so that they are in opposing positions.
[2] Installation of travel motor
1) Install the travel motor on the work platform. Note
• While aligning the travel motor with the threaded holes on the hub [1] and on the work platform, gently insert the travel motor into the installation holes on the work platform.
2) Install the travel motor on the work platform so that the 2 hexagon socket head bolts are in opposing positions. Caution Note
• Thoroughly tighten the hexagon socket head bolts. If they are not thoroughly tightened, the travel motor can fall and cause injury when it is inverted.
34
