Travel Unit
AL
Name: oil seal press-fit jig • Part for press fitting the oil seal [132] in the oil seal installation hole of the spindle [2].
Name: primary bearing press-fit jig
IN
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
Name: steel rod (I) • Part for removing the ring [45] from the hub [1].
TE RN
• Part for press fitting the ball bearing [24] in the hub [1].
Name: primary bearing precompression adjustment jig
• Part for installing the ring nut [22] on the spindle [2].
Name: long eyebolt
• Part for lifting the travel motor, spindle [2], and hub [1]. Application
"A"
Hub
M14
Spindle
M16
Travel motor
M16
Name: scoop • Used when removing the timing plate [109] from the rear flange [301].
30
ASM-17-21-002EN 3
