Hydraulic Pump
TE RN
AL
[8] Install the 2 parallel pins on the front frame.
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
[9] Install the front frame.
(2) Assembly of gear pump (G1)
[1] Install the drive gear on the housing. [2] Install the idle gear.
[3] To prevent falling, coat the angle rings and backup rings with grease and install them on the side plate in that order.
19
ASM-17-20-002EN 19
