Model 6210 Maintenance Manual
Section 3.Systems Overview Operator Display and Programming
Parameter
Name
36
Customer Option
Range (Step)
Default
Description
0 to 2
0
Parameter 36 supports alternative input options for the handle head rocker switch. 0 = None 1 = Lift-Limit with Bypass (if truck equipped) 2 = Secondary Horn
NOTE: Lift-Limit with bypass and horn are mutually exclusive. 37
Not used
38
Not used
39
Access Code
1 to 4
1
Defines whether truck has a key switch or a keypad and what access level service personnel have to parameters. 1 = key switch only (no key pad)/operator parameters are open, 2 = key switch only (no keypad)/operator parameters are closed, 3 = keypad/operator parameters are open, 4 = keypad/operator parameters are closed. (When operator parameters are closed, Service Key is required to access operator parameters.)
40
Pendant Control
0 to 5
0
0 = Pendant Control Disabled 1 = 10% of maximum lowering speed empty 2 = 16% of maximum lowering speed empty 3 = 33% of maximum lowering speed empty 4 = 66% of maximum lowering speed empty 5 = Maximum lowering speed empty
41
Click-to-Creep
0 to 4
1
Enables creep travel with the tiller arm in the fully raised or lowered position. 0: Disable 1: Approximately 0.5 MPH 2: Approximately 1 MPH 3: Approximately 1.5 MPH 4: Approximately 2 MPH Activate click-to-creep by clicking the speed control thumb wheel in either direction twice with the tiller in the brake position. “SLO” blinks on the display when in click-to-creep mode. Deactivate by clicking the speed control thumb wheel twice again. Also, the mode deactivates automatically after 10 seconds or immediately if the emergency reverse (belly button) switch is pushed.
42
Proportional Valve End Point
65 to 255
105
Sets the maximum proportional valve raw data value. The larger the number, the higher the maximum allowed PWM to the proportional valve. This determines the maximum flow rate during a lower.
