Model 6210 Maintenance Manual
Section 3.Systems Overview Operator Display and Programming
Parameter
Name
Range (Step)
18
iPORT Init Speed (only with iWAREHOUSE option)
0.1 to 3.9 representing 0 MPH to FULL SPEED
Default
Description
3.8
Prior to communication with the SWM, iPORT Initial Speed sets the maximum allowable truck speed.
NOTE: A 0 MPH setting disables truck functions. NOTE: Raymond recommends that Init Speed be set to 0.5 (0.8 km/h) to prevent operation without being logged in.
19
iPORT Error Speed (only with iWAREHOUSE option)
0.1 to 3.9 representing 0 MPH to FULL SPEED
3.8
The Error Speed limit is activated when communication is interrupted and the truck comes to a stop. When communication is re-established, and throttle is brought back to neutral, normal operation is restored.
NOTE: Raymond recommends that Error Speed be set to 1.0 MPH (1.6 km/h). 20
Hour Meter Selection
1 to 3
2
1 (A) = key time 2 (b) = activity time (drive, lift, or lower) 3 (c) = travel time
21
Battery Type
1 to 3
2
Defines battery type for correct BSOC (battery state-of-charge) configuration. 1 = Industrial battery 2 = AGM battery 3 = Wet Cell battery and NEXSYS battery pack
22
Not used
23
Not used
24
Battery Reset Level
50 to 100%
75%
Reset value for BSOC function. The displayed BSOC value must be below the selected level at key OFF before a fully charged battery will reset BSOC to 100% at key ON or reset to 100% when the voltage at key OFF is above the reset level. When battery BSOC level drops below this level, the truck will allow the BSOC to reset once Reset Voltage (Parameter 44) is reached.
25
Not used
26
Sequencing Delay
100 to 500 ms
200 ms
Creates a sequencing delay to allow for throttle engagement just before the brake is released. The Sequencing Delay timer is enabled when the throttle is engaged while the brake is applied. If the timer expires before the brake is released, error code ‘Hpd’ is generated by the VM.
27
Not used
28
Not used
Publication: 1146947, Revised: 12 Jan 2017
3-15
