Section 3.Systems Overview
Model 6210 Maintenance Manual
Operator Display and Programming Table 3-3.
Service Parameters
Parameter
Name
10
PIN code (keypad only)
Range (Step)
Default
Description
0 to 9999
1
Capability to assign up to 10 PIN-key codes (for 10 different operators). A Service Key is required to assign up to 10 operators their own PIN-key code (one to four digits) for access to the truck. See “Setting Individual PIN-Key Codes” on page 3-13.
NOTE: 0 disables a driver (the 2nd through 10th driver’s default PIN is 0). If all drivers are disabled, the truck cannot be driven without the service key.
NOTE: If two drivers have the same PIN number, the parameters of the driver with the highest settings are used for both drivers. 11
Not used
12
Throttle Map
20 to 80%
50%
Alters the slope of the calculated throttle. 50% is a linear throttle response. >50% provides a more rapid increase in speed at lower throttle requests. <50% provides a slower increase in speed at lower throttle request. Maximum speed is achieved at full throttle for all response curves.
13
Brake Deceleration Rate (Plugging)
1 to 5
3
Selects from a table for deceleration rate. A higher number results in a less aggressive deceleration. 1 = hardest feel 5 = gentlest feel
14
Run-Time Display
0 or 1
0
0: BSOC is the default run-time display. At power-up the Hour Meter briefly displays, then the BSOC percent is displayed during run-time 1: Hour Meter (as selected by parameter 20) is the run-time display. At power-up the BSOC percent briefly displays, then the Hour Meter is displayed during run-time.
NOTE: A setting of “1” is useful for trucks with fuel cells. 15
Not used
16
Travel Alarm Type
17
Not used
3-14
0 to 7
0
0 = No Alarm 1 = Tractor-First Alarm 2 = Forks-First Alarm 3 = All Travel Alarm 4 = Low Battery Alarm 5 = Low Battery and Forks-First Travel Alarm 6 = Low Battery and Tractor-First Travel Alarm 7 = Low Battery and All Travel Alarm
Publication: 1146947, Revised: 12 Jan 2017
