Programming Service Parameters NOTE: A service key is required to change service parameters. See “Service Key” on page 3-7. 1. Connect the service key to the service key connector J5. Make sure the Main ON/OFF switch (SW1) is in the ON position. See “Special Tools” on page 3-6. 2. Turn the truck ON while holding the horn button until “P” is displayed. Release the horn button at “P” to enter parameter mode. The Parameter indicator (wheel icon) on the display illuminates when in parameter mode. See “Special Truck Mode” on page 3-8. If the horn button is released at the wrong time, turn the truck OFF and start over. 3. Rotate the thumb control in the fork direction to progress forward through the parameters. While the thumb control is held and briefly after it is released, both the parameter number and the driver number are displayed. Stop at parameter 10 (PIN code) for the first driver; the default value of “1” is displayed. See Figure 3-6 on page 3-8.
Parameter Display When parameters 1 through 5, and 10 are viewed with the service key, both the parameter number (left side of display) and the 1st operator number (right side of display) are shown. As the parameter number display progresses through parameters 1 through 10, the display rolls over to the next operator (the operator number increases). If a parameter is changed, it is valid only for the operator shown. After all operators and operator parameters are scrolled through, Service Parameters 11 through 49 are displayed. To quickly display/access a Service Parameter, rotate the thumb control away from the forks (sequence backwards through the parameters/operators).
4. Press the horn button once to access this parameter. The parameter symbol on the display flashes. Now you can make changes to the value of the first driver’s PIN code. See Table 3-2, “Truck (Operator) Parameters,” on page 3-11. NOTE: All parameters can be viewed; however, not all parameters can be changed. Driver parameters may or may not be accessed, depending on the value of parameter 39.
