Model 6210 Maintenance Manual
Section 3.Systems Overview Operator Display and Programming
Table 3-2.
Truck (Operator) Parameters
Parameter
Name
Range (Step)
Default
Description
01
Max Speed
0 to 40%
40%
This parameter controls the scaling of the throttle request. A setting of 40% corresponds to approximately 3.6 MPH.
02
Not used
03
Not used
04
Neutral Braking (Deceleration)
0 to 6
5
Defines the truck’s neutral braking characteristic when the throttle is returned to neutral. A higher number results in a less aggressive deceleration. 6: low reduction force 0: high reduction force
05
Truck OFF Delay (with optional keypad only)
0 to 20 min.
0 min.
Sets the truck off delay (energy saving feature). If this amount of time passes while the tiller arm is in a brake position and the truck is idle (no outputs requested), the VM powers the truck OFF. When this parameter is set to 0, the truck never powers OFF. If parameter 39 is 1 or 2 (truck does not have an optional keypad), the truck never powers OFF. 0: never turns off 20: 20 minutes.
06
Not used
07
Acceleration Rate
1 to 5
3
Selects from a table for acceleration rate. A higher number results in a less aggressive acceleration. 1 = fastest, 5 = gentlest.
08
Not used
09
Not used
Publication: 1146947, Revised: 12 Jan 2017
3-11
