Section 3.Systems Overview
Model 6210 Maintenance Manual
Lift Truck Specifications
Lift Truck Specifications This lift truck is rated for performance by load center, load weight, and load height with forks elevated. Review the specification tag located on the lift truck’s left mast upright for detailed load capacity and load center information. See Figure 3-2. Figure 3-2.
A second specification tag is located inside the tractor compartment on the right side bulkhead plate as you face the tractor compartment. A battery specification tag is located on the left side of the top of the battery when facing the truck from the operating position. See Figure 3-3. Due to continuous product improvement, specifications are subject to change without notice or obligation.
Lift Truck Specification Tag SPECTAG.WMF 412-852_C.EPS
Raymond model
Serial number
Approximate weight of lift truck minus battery, load, and operator
Maximum load capacity for this lift truck
Minimum battery weight for this lift truck Maximum battery weight for this lift truck Battery weight must be between the minimum and maximum weight
Hour rating of battery
3-4
Nominal battery voltage
Publication: 1146947, Revised: 12 Jan 2017
