Switches
Electrical Components
2-Position Keyed Switch (Optional) A 2-position keyed Main ON/OFF switch is available as an option.
Replacement Figure 7-67.
Main ON/OFF Switch - Keyed Option
Arm Angle Proximity Switch The arm angle proximity switch is found at the base of the tiller arm stem. SW2 determines brake activation and truck travel. The switch is activated by the control handle position. The control handle must be in the T1 position in order for the switch to be closed, permitting travel. See Figure 7-68. Figure 7-68.
2-Position Keyed Main ON/OFF Switch
Brake Actuation
B1 T1
B2
1. Place the Main ON/OFF Switch in the OFF position. Disconnect the battery connector from the truck.
Replacement
2. Remove the tractor covers.
1. Lower the forks completely.
3. Disconnect the wires from the switch terminal.
2. If equipped with the optional keypad, press the red OFF ( O ) key. Place the Main ON/OFF Switch in the OFF position. Disconnect the battery connector from the truck.
4. Remove the key switch. 5. Install the new key switch. 6. Install the tractor covers. 7. Reconnect the battery connector.
3. Remove the tractor covers. 4. Disconnect the wires from the switch. 5. Remove the screws and carefully remove the bracket and switch. 6. Remove the screws holding the switch on the mounting bracket. Remove the switch. 7. Mount the new switch to the mounting bracket. 8. Install the bracket and screws. 9. Connect the wires to the switch. 10. Reconnect the battery connector. Place the Main ON/OFF Switch in the ON position. Press the green ON ( | ) key on the keypad, or turn the optional key switch ON. 11. Test the operation of the truck.
