Model 6210 Maintenance Manual
Section 7. Component Procedures
Steering and Controls
Control Head Assembly
Control Head Installation Do not use excessive force when prying on the button or you can damage the locking tabs. Figure 7-20.
Horn Button P0011000.wmf
NOTE: Callouts in this procedure refer to the illustration on page 7-15. NOTE: Place a finger between the housing [21] and the emergency reverse button [14] to hold the right rocker [33] in place while installing the housing [21]. 1. Install the lift/lower rocker assembly [12] and [13]. See Figure 7-21. 2. Install the thumb wheel assembly [30]. 3. Install the horn button [15] and [41]. See Figure 7-20. 4. Install the housing [21]. Secure with the screws [22]. 5. Connect the cable to the control card [19].
10. Disconnect the connection for the switch on the control card [19]. 11. Press the switch out from its mounting in the top cover assembly. 12. Remove the thumb wheel assembly [30]. 13. Remove the lift/lower rocker assembly [12] and [13] screws. See Figure 7-21. Figure 7-21.
Lift/Lower Button P0011002.wmf
6. Install the top cover [16] and hold firmly in place while securing with screws [4] and [8]. 7. Plug the keypad [6] into the handle [3]. Secure with screws [7]. 8. Remove the blocks. 9. Reconnect the battery connector. Place the Main ON/OFF Switch in the ON position. If equipped with the optional keypad, enter your PIN-key code and then press the green ON ( | ) key. 10. Test the operation of the truck.
Publication: 1146947, Revised: 12 Jan 2017
7-17
