Model 6210 Maintenance Manual
Section 6. Messages and Codes Delta-Q Charger Codes
Code
Description
Solution
E-0-2-9
Cannot transmit on CAN bus
• Check the physical CAN connector, electrical bus conditions and other CAN modules for correct functioning. For example, check termination resistance is approximately 60 ohms.
E-0-3-0
CAN heartbeat timeout on battery module
• May be caused by a missing heartbeat message. Check the CAN Bus battery module for correct function. This error will automatically clear once the condition has been corrected.
E-0-3-1
The Vref for the ADC measurements has triggered an alarm
• Internal charger error. Remove AC and battery for minimum 30 seconds and retry charger. • If the problem continues to exist, please contact the manufacturer of your vehicle or machine. This error will automatically clear once the condition has been corrected.
E-0-3-6
Battery temperature sensor is missing or shorted
• Check if sensor is connected correctly • The charger behavior when this fault occurs can be configured. This error will automatically clear once the condition has been corrected.
E-0-3-7
CANOpen reprogramming failed
• Re-try CANOpen download or re-program using the USB. This error will automatically clear once reprogramming has completed successfully.
E-0-3-8
Fan will not turn
• Check fan connections for loose wires. • Check rotor is not locked, or fan is not obstructed. Inspect the fan and clear the blockage. This error will automatically clear once the condition has been corrected.
E-0-4-0
Fan voltage pulled low
Publication: 1146947, Revised: 12 Jan 2017
• Make sure the fan is not stuck, sticking, or otherwise overloaded.
6-45
