82 INSTRUMENTS AND CONTROLS • Motorized-Mirror Joy Stick – This control is designed like a "joy stick." ROTATE the stick to the right to control the right mirror. ROTATE the stick to the left to control the left mirror. PUSH the stick up, down, left or right, as indicated, to correctly position the selected mirror.
C0029215
• Power Divider Lockout Switch – See "Inter-Axle Power Divider Lockout (If Equipped)" in the OPERATION section of this manual. • Power Take-Off Control Switch — Push the top in to turn the PTO on. Push the bottom in to turn it off. • Push Axle Up/Down Switch — The operator controls the raise and lower functions with the instrument panel-mounted auxiliary axle switch(es), and axle loading is controlled by the air regulators which are located inside the cab between the driver and the rider seats. There is one regulator for each axle. Note: To prevent frame damage, the auxiliary axle(s) will automatically raise when the transmission is shifted into reverse.
C0029216
1. Air Pressure Gauge
2. Air Pressure Regulator
